11/17/09 08:45 pm - Mitsubishi Lancer Head Unit removal
1. Remove all 3 HVAC knobs. It feels difficult but you just need to give it a good yank!
2. Unscrew 2 screws inside pocket holding it to the trim panel, both screws are inside at the top.
3. Unscrew 2 screws behind temperature knob and vent selector knob.
4. Remove trim panel around radio and HVAC controls. Do this by gently prying it away, starting from the holes behind the HVAC knobs. It might feel a little bit tough at the start but just give it a good tug and it'll all come off!
5. If you need to, unscrew 4 screws holding radio in place, two on left, two on right.
Otherwise you'll just be able to access the back of your radio unit and plug in the RCA cable into your head unit! Installation is just the reverse of the steps outlined above.
6. Pull radio out.
7. Unscrew 2 screws from adapters, one on each side.
8. Remove wiring harness and antenna cable.
